Eco Friendly Detachable Container House
1) 20ft: 6000*2438*2596mm
2) Or customized size
3) Roof Type: Flat roof with injected PU insulation
4) SOC pakcing for easy handling
Product Introduction
Eco Friendly Detachable Container House Material List | |
A: Standard unit materials | |
2.435W*6L*2.791H flatpack container block | Each unit including: 1: Chassis ( steel structure+18mm fiber-cement board +1.8mm PVC floor sheet) 2: Roof structure (steel structure+0.4mm color-bond steel roof sheet+100mm glass wool insulation+0.4mm color-bond steel ceiling sheet) 3: Column 4: electrical system (lamp, switch, socket, cable, DB) |
wall panel | 75mm EPS sandwich panel, both sides are 0.4mm thickness color bond sheets |
steel door D1 | steel frame: 860x2080mm |
sandwich panel door D2 | steel frame: 700x2000mm |
aluminum sliding window W1 | Alu frame+5mm single glazed: 800x1100mm |
aluminum sliding window W2 | Alu frame+5mm single glazed: 800x400mm |
exhaust fan | PVC frame |
PVC trim plate | skirting, corner and ceiling |
united materials between containers | include bolt, flashing, floor plate and article rubber |
color bond flashing | 0.5~0.5mm color bond steel plate |
Design Parameters
Design parameter | 1) Life span: up to 20years |
2) Floor Live load: 2.0KN/m2 | |
3) Roof Live load: 0.5KN/m2 | |
4) Wind load: 0.6KN/m2 | |
5) Earthquake-resistance: Grade 8, Fire-proof: Grade 4 |
Advantages
Flexiable design
Eco Friendly Detachable Container House is flexiable for space design. we have standard 6*2.4m, 6*3m, 9*3m or any other dimensions you need.
We can also combine different detachable container house into large space for some commerical or public projects such as school, office, showroom...
Termite and Insect resistant
Prefab container house floor uses 1.8mm PVC floor +18mm cement fiber board. Wall Panel uses 75mm EPS sandwich panel, material option is PU, rock wool. Colored steel sheet is 0.40m. Panel's outside is color-optional with ribs, inside is milky white. The steel sheet surface is Aluminum Zinc galvanized 50g/m2+ PE baking finish 15/5um.
There is no surface for termites to eat. Also, due to the solid construction of the container, the only openings for pests of any kind to enter the container is through any openings cut into the container for doors and windows. All of these openings are insulated and caulked/silicone to prevent weather and insects or rodents from entering. You can put one of these container cabins in the middle of the woods and be confident that it will not be destroyed by insects.
Quick Build Time
Normally will take only 8-10 hours to finish install one unit by 2 workers. this will also save a lot of installation time and cost.
Production
We are top manufacture in China because we are:
Pioneer in this industry to provide for oversea projects. In Year 2007 we started to export flatpack container house, there’re only several competitors in China at that time. In Year 2011 we are the first batch to use FrameCAD machine and software to start the light gauge steel house business, and was the first one in China who can provide 70mm, 89mm and 140mm light gauge steel sections;
We created a unique flatpack container house system: the PU injected foaming container roof is patented; all frames assembling and welding are in the special jigs to make sure the correction of the dimensions and angles; all steel sections are customized cold rolled; all steel is galvanized…
We are the first one in this industry to use robot arms for welding.
Applications
Construction site office or accommodation camp;
Mining site office or accommodation camp;
Isolation rooms;
COVID hospital;
Temporary office or living house
Low-cost house;
Granny backyard flat;
Kiosk booth;
Guard house;
Rent for other temporary use.
Related Projects
| Project Name | MTI Accommodation Camp | ||
| Finished Time | Year 2022 | ||
| Project Place | Indonesia | ||
| Building Area | 288 rooms with ensuite in three floor, 8 buildings | ||
| Project Description | 8 Staff accommodation buildings for PT. Merdeka Copper Gold. Each block in three floors, 12 rooms with ensuites in every floor, 36 rooms combine into one block. CBC designs, provides all materials, accessories, facilities within two months. | ||
| Project Name | AMMAN Accommodation Camp | ||
| Finished Time | Year 2022 | ||
| Project Place | Indonesia | ||
| Building Area | 480 rooms with ensuite | ||
| Project Description | 6 Staff accommodation buildings for AMMAN. Each block in two floors, 40 rooms with ensuites in every floor, 80 rooms combine into one block. CBC designs, provides all materials, accessories, facilities. All pods customized for our client. |
Philippines:
SCPA workshop-3200sqm with Eco Friendly Detachable Container House office inside
SG Eco workshop-3600sqm warehouse with two floors office in 250sqm,
Iriga Factory,
BBL Camp—24 rooms accommodation camp with public services such as dining hall, gym room;
Maria De Sio Resort-320sqm
SMMCI Camp—1300sqm office building built by Insulated Flat Pack Container House and 2600sqm warehouse
| Project Name | SMMCI Project | ||
| Finished Time | Year 2013 | ||
| Project Place | South Manila, Philippines | ||
| Building Area | 2600 S.qm warehouse plus 1700sqm office/camp facility | ||
| Project Description | For "San Mining CONST. CORP.", use as onsite warehouse, office, camp and other facilities. Full package provided by us. | ||
| Project Name | Camp in Lao | ||
| Finished Time | Year 2019 | ||
| Project Place | Lao | ||
| Building Area | 56 units | ||
| Project Description | Accommodation and office blocks made of flat pack container houses, most are two floors. Meets with AU standards. |
FAQ
Q: What's your supply capacity?
A: Annual production capacity details are as follows:
Container house: 7200sets
Prefab house; 564000 square meters
Steel structure: 360000 square meters.
Q: How do you guarantee the quality of the products?
A: Quality is the future. Quality is the top priority.
We have a five people QC team inspecting production daily, they will follow the shop drawings strictly and check every part/project at the beginning, in the middle and for finished products.
We can also assemble some units in our factory for some special customized projects to make sure everything is good enough.
Q: How can I get a quotation for my project?
A: We can offer detailed quotations according to your drawing. If you have no drawing, our designer can offer you some designs based on your detailed requirements. Quotations will be provided after the confirmation of the designs.
Q: How do you guarantee the quality of the Eco Friendly Detachable Container House?
A: Quality is the future. Quality is the top priority.
We have a five people QC team inspecting production daily, they will follow the shop drawings strictly and check every part/project at the beginning, in the middle and for finished products.
We can also assemble some units in our factory for some special customized projects to make sure everything is good enough.
