Portable Container House
Portable Container House
Weight: 1500kg
Color: White, blue, green, brown, or customized
Roof: 2.5-3mm Hot galvanized steel structure with 4 corner casts and injected PU foaming.
Columns: 3mm Hot galvanized steel structure
Product Introduction
Specifications of Portable Container House
Portable container house requires no concrete foundation, it can be put on a firm and flat ground directly. and you can lift it with a folklift or a small crane from the four roof corners, so it is very convenient to be relocated. here are the specifications of our portable container house:
|
Size |
Length |
6058mm / 6000mm or customized |
|
Width |
2438mm /3000mm or customized |
|
|
Height |
2600mm / 2791mm / 3000mm or customized |
|
|
Clear height indoor |
5800mm*2200mm*2300mm, or custom-made dimensions for special projects |
|
|
|
Roof System |
Roof structure made by 2.5~3mm thick Q355 galvanized steel, cold rolled special sections, high strength + 70mm thick integrated PU foam insulation + embedded electrical system |
|
Roof loading:>1.0KN/m2, can walk on the roof directly |
||
|
Base System |
Q355 galvanized steel structure chassis (2.5~3mm thickness) + 18mm cement-fiber board + 2mm PVC floor sheet (glass wool insulation for optional) |
|
|
Floor loading:>2.5KN/m2 |
||
|
Wall System |
T=50/75/100mm EPS / rock wool / glass fiber / PU sandwich panel, 0.4mm color-bond steel on both sides |
|
|
Door System |
Steel door / Fire-proof door / Sandwich panel door |
|
|
Window System |
Aluminum alloy or PVC window, single or double glass |
|
|
Floor System |
PVC, plywood or customized |
|
|
Option |
Drainage system |
Full embedded in factory, can be customized |
|
Electric system |
Pre-installed in factory, can be customized |
|
|
Technical Parameter |
Suitable temperature |
-40ºC to 40ºC |
|
Wind resistance |
210km/h |
|
|
Seismic resistance |
Grade 8 |

Frame: Q355 steel structure is hot-dip galvanized and completed welding, coated with hot galvanized zinc 100g/m2+surface uses electrostatic powder treatment finish 100um. Q355 Steel is better than Q235, and with HDG treatment with powder spraying, it would keep the frame in high anti-corrosion.
Roof: For the roof, our cases is PU foaming (45kg/m3 which meets standard of PIR) which has high integrity for the airtightness which would be better than common EPS sandwich panel or glass wool as roof insulation.
Panel: For the sandwich panels, we remark with density and thickness of both sides of steel sheets, in the same time, you can find the treatment with Aluminum zinc magnesium AMZ galvanized 100g/m2 with PE baking finish 20/5um. which can last more than 25 years.

Advantages of Portable Container House
Portable container houses have become increasingly popular in recent years as a more efficient and cost-effective housing solution. These houses are made from repurposed shipping containers and can be easily transported and assembled in various locations. As we look at the current state of the portable container house industry, we see a bright future ahead.
One factor driving the growth of the portable container house market is the global rise in population, coupled with shrinking living space. Many people are seeking affordable and sustainable housing solutions that allow them to live comfortably while minimizing their environmental impact. Portable container houses can meet these needs while also providing versatility and flexibility.
Another factor contributing to the growth of this market is the convenience of these houses. Portable container houses can be constructed in a matter of weeks as compared to months or years for traditional housing. This makes them a great option for those who need a quick and temporary housing solution, such as disaster relief shelters, remote work sites, and military barracks.
In addition to being cost-effective and practical, portable container houses can also be designed to be aesthetically pleasing. With the help of modern architectural techniques and creative design, container houses can be transformed into chic and stylish homes. People around the world are increasingly turning to container homes to fulfill their dream of owning unique and sustainable housing.
Moreover, there are many companies emerging in the market that specialize in building portable container houses. These companies offer a wide range of services, from design and customization to delivery and installation, making it easier than ever to own a container home. With the increasing demand for these houses, we can expect to see more companies enter the market, resulting in even more competition and innovation.
Government support is also a driving factor in the growth of the portable container house market. In many countries, governments are recognizing the value of these houses as a solution to the affordable housing crisis. They are providing financial aid and subsidies to encourage the construction of affordable housing.
In conclusion, the current state of the portable container house industry is promising. With increasing population and shrinking living space, there is a growing demand for affordable and sustainable housing solutions. Portable container houses provide an excellent solution to this need, and they are being embraced by people around the world. As more companies enter the market and governments continue to support their construction, we can expect to see even more growth and innovation in the years to come.
