CBC Modular Container Camp Master Plan for Indonesian Mining Operation
Prepared in accordance with CBC Company Standard Detachable Container House Specifications

---

Client: Mining Company in Indonesia

Location: Remote mining site, Indonesia (final delivery inland from Jakarta port)

Accommodation Requirements:

Management Staff: 100 persons (single occupancy)

Workers: 1,000 persons (double occupancy)

Support Facilities: Dining hall, clinic/hospital, laundry, public toilets & showers, library, recreation, and activity spaces, admin offices, gym, etc.

Module Specification (CBC Standard):

Dimensions: 3.0 m (W) × 6.0 m (L) × 2.7 m (H)

Integrated bathroom: Toilet + shower + sink (fully plumbed)

Wall/roof: 50–75 mm rock wool sandwich panels (fire-rated, insulated)

Floor: Steel frame + plywood + PVC/vinyl finish

Windows: Aluminum-framed, mosquito-screened, with blinds

Electrical & lighting pre-installed; plumbing roughed-in

Key Transport Fact: Each standard 40-ft high-cube shipping container can accommodate 16 detachable CBC modules (flat-packed or nested). This significantly reduces ocean freight cost per unit.

---



Function	Occupancy / Capacity	Modules Required	Notes
Management Housing	100 single rooms	100 modules	1 person/module
Worker Housing	1,000 persons @ 2/person	500 modules	Bunk beds, 2 per module
Dining Hall	300 seats per shift (3 shifts)	30 modules	Open-plan layout
Central Kitchen	Serving 1,100 meals/shift	12 modules	Includes storage, prep, cooking
Clinic / Mini-Hospital	Basic medical + isolation	8 modules	Exam, pharmacy, 2-bed ward
Laundry Facility	1,100 users	6 modules	Industrial machines + folding area
Library & Study Area	Expanded capacity	12 modules	Each 6 modules(×2)
Gym & Recreation Center	Cardio, weights, lounge, games	16 modules	Each 8modules (×2)
Security & Reception	Gatehouse + control room	4 modules	Perimeter entry
Admin & Meeting Rooms	Offices, IT, printing	6 modules	Included in support block
Utility / Storage	Cleaning supplies, spare parts	6 modules	Lockable units
TOTAL		700 modules	All standard detachable container house

Note: All residential and functional modules include integrated bathrooms-no standalone toilet/shower blocks required, ensuring hygiene and operational simplicity.

---



3.1 Key Logistics Update

Total Modules: 700

Modules per 40-ft HC Container: 16

Required Shipping Containers: 700 ÷ 16 = 43.75 → 44 containers

Ocean Freight Rate (Hangzhou → Jakarta): ~$2,800/container (2026 market avg.)
→ Freight per module: $2,800 ÷ 16 = $175/module (vs. previous $300)



3.2 Cost Breakdown

Cost Component	Unit Cost	Quantity	Total (USD)
Container Modules (CBC Standard)	$2,000	700	$1,400,000
Ocean Freight (Hangzhou → Jakarta)	$175	700	$122,500
Marine Insurance	0.8% of FOB	-	$11,200
CIF Value (Modules + Freight + Insurance)	-	-	$1,533,700
Indonesian Import Duties & VAT	~15% of CIF*	-	$230,055
Port Handling & Customs Clearance	$120/module	700	$84,000
Inland Transport (Jakarta → Site)	$220/module (bulk discount)	700	$154,000
On-Site Installation & Commissioning	$190/module (efficiency gain)	700	$133,000
Site Works (Grading, Roads, Drainage, MEP Tie-ins)	Lump sum	-	$160,000
Contingency (10%)	-	-	$263,781
TOTAL PROJECT BUDGET			$2,558,536

Assumptions:

Import duty: 7.5% + VAT: 11% ≈ 15% effective on CIF value

Inland transport reduced due to full-truckload efficiency

Installation cost slightly lower due to standardized layout and volume

Cost per Person Accommodated (1,100 total): ~$2,326
Average Cost per Module (all-in): ~$3,655

---





✅ Improved Quality of Life

Double-sized communal facilities (library, gym, recreation) promote mental well-being, reduce fatigue, and support workforce retention-critical in remote mining operations.

Quiet study zones, fitness areas, and social lounges align with modern ESG and occupational health standards.

✅ Optimized Logistics & Cost Savings

High packing density (16 modules/40-ft container) slashes ocean freight by ~42% vs. initial estimate.

Fewer container moves reduce port congestion, demurrage risk, and handling damage.

✅ Operational Resilience

Private bathrooms in every unit eliminate dependency on centralized sanitation-reducing water distribution complexity and outbreak risks.

Modular redundancy allows easy replacement of damaged units without disrupting camp function.

✅ Scalability & Future Use

The camp can be reconfigured post-project into a community center, school, or disaster relief base.

Flat-pack design enables efficient return transport if needed.

✅ Compliance & Sustainability

Meets ISO 9001/14001 factory standards; materials comply with Indonesian SNI for temporary structures.

Reduced carbon footprint due to efficient shipping and minimal on-site construction waste.

✅ Speed of Deployment
Factory production concurrent with site prep → camp ready in 8–10 weeks from order
Modules arrive 90% complete; only MEP connections and leveling required on-site
✅ Superior Living Standards
Every unit has private, lockable bathroom-eliminates queues, improves sanitation, reduces disease risk
Insulated panels ensure thermal comfort in tropical climate (reduces need for AC)
Durable, corrosion-resistant materials suitable for humid, coastal, or jungle environments
✅ Scalability & Flexibility
Modular grid layout allows future expansion or reconfiguration
Units can be relocated or repurposed post-mining (e.g., schools, clinics)
✅ Cost Efficiency
Lower lifecycle cost vs. traditional construction in remote areas
Reduced labor dependency on-site (minimal skilled labor needed)
✅ Compliance & Safety
Meets international standards for fire resistance (EN 13501), structural wind load (up to 120 km/h), and seismic resilience (low-to-moderate zones)
Pre-certified for export; simplifies Indonesian customs process
✅ Sustainability
Steel structure is 95% recyclable
Energy-efficient design lowers operational carbon footprint

---



The customized CBC modular camp plan accommodates 1,100 personnel with enhanced welfare infrastructure at a highly competitive all-in budget of just under $2.56 million. By leveraging the high-density shipping capability (16 units per container), the project achieves significant logistics savings while doubling communal amenities-directly supporting worker morale, productivity, and corporate social responsibility goals. This turnkey, rapidly deployable solution is ideally suited for mining operations in Indonesia and other Southeast Asian regions requiring durable, humane, and cost-effective temporary infrastructure.
